GeForce RTX® 4090 SUPRIM X 24G

• TRI FROZR 3S - Push performance with the latest MSI cooling design and elevate sophistication with a prestigious appearance.
• TORX FAN 5.0 - Fan blades linked by ring arcs and a fan cowl work together to stabilize and maintain high-pressure airflow.
• Vapor Chamber - The GPU and memory modules are covered with a Vapor Chamber which rapidly transfers heat to Core Pipes.
• Core Pipe - Precision-machined heat pipes ensure max contact and spread heat along the full length of the heatsink.
• Airflow Control - Sections of different heatsink fins disrupt unwanted airflow harmonics and reduce noise.
• Zero Frozr - The fans completely stop when temperatures are relatively low, eliminating all noise.
• Metal Backplate - Thermal pads under the sturdy metal backplate provide additional cooling while the flow-through ventilation reduces trapped heat.
• Wave Curved 3.0 - Additional efficiency is gained by adjusting the size of the wave edges under the fan motor and other spots where there is less airflow.

MODEL NAME

GeForce RTX® 4090 SUPRIM X 24G

GRAPHICS PROCESSING UNIT

NVIDIA® GeForce RTX® 4090

INTERFACE

PCI Express® Gen 4

CORE CLOCKS

TBD

CUDA® CORES

16384 Units

MEMORY SPEED

21 Gbps

MEMORY

24GB GDDR6X

MEMORY BUS

384-bit

OUTPUT

DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K @120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI 2.1a)

HDCP SUPPORT

Y

POWER CONSUMPTION

TBD

POWER CONNECTORS

16-pin x 1

RECOMMENDED PSU

850W

CARD DIMENSION (MM)

336 x 142 x 78 mm

WEIGHT (CARD / PACKAGE)

2413g / 3636g

DIRECTX VERSION SUPPORT

12 Ultimate

OPENGL VERSION SUPPORT

4.6

MAXIMUM DISPLAYS

4

G-SYNC® TECHNOLOGY

Y

DIGITAL MAXIMUM RESOLUTION

7680 x 4320
