HPE PL DL360g11 4514Y (2.0/16C) 1x32G (p64706) MR408i-o/4G 8-10SFF 1000W 2x10G-T 1U RENEW P70542-421
HPE PL DL360g11 4514Y (2.0/16C) 1x32G (p64706) MR408i-o/4G 8-10SFF 1000W 2x10G-T 1U RENEW P70542-421
HPE PL DL360g11 4514Y (2.0/16C) 1x32G (p64706) MR408i-o/4G 8-10SFF 1000W 2x10G-T 1U RENEW P70542-421
SKU Number P70542-421
Model Name HPE PL DL360g11 4514Y (2.0/16C) 1x32G MR408i-o/4G 8-10SFF 1000W 2x10G-T NBD333 1U
Chassis HPE ProLiant DL360 Gen11 8SFF NC Configure-to-order Server
CPU 4514Y (16 core, 2.0 GHz, 150W)
Number of Processors One with standard heatsink
Memory 32 GB (1x32 GB , 5600 MT/s) Notes: Runs at 4800 MT/s due to processor limitation
Network Controller Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE Notes: No embedded networking
Storage Controller HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Hard Drive None Included
Internal Storage 8 SFF NC CTO Server (upgradeable to 8+2 SFF front)
PCIe Slots 2-slots (x16 FH, x16 HH). Upgradeable to 3rd slot in HH (or remove Slot 2 bracket to be FH at Slot 3) in 2nd CPU configuration.
Power Supply 1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Fans 5 - Standard
Management HPE iLO 6
Security Trusted Platform Module (TPM) Notes: Enabling TPM 2.0 no longer requires TPM module option kit for Gen11. It is an embedded feature and can be disabled in the BIOS setting.
Rail Kit HPE ProLiant DL3XX Gen11 Easy Install Rail 3 Kit Notes: Server does not support shelf mounted rail kits ("L" brackets).
Energy Star Energy Star 3.0
Form Factor 1U Rack
Warranty 3-year parts, 3-year labor, 3-year onsite support with next business day response.
| SKU Number | P70542-421 |
| Model Name | HPE ProLiant DL360 Gen11 4514Y 2.0GHz 16-core 1P 32GB-R MR408i-o NC 8SFF 1000W PS Server |
| Chassis | HPE ProLiant DL360 Gen11 8SFF NC Configure-to-order Server |
| Processor | 4514Y (16 core, 2.0 GHz, 150W) |
| Number of Processors | One with standard heatsink |
| Memory | 32 GB (1x32 GB , 5600 MT/s) Notes: Runs at 4400 MT/s due to processor limitation. |
| Network Controller | Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE Notes: No embedded networking |
| Storage Controller | HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| Included Hard Drives | None ship standard, 8 SFF supported |
| Internal Storage | 8 SFF NC CTO Server (upgradeable to 8+2 SFF front) |
| Optical Drive | Optional - HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive. |
| Power Supply | 1x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
| Fans | 5x Standard Fans |
| Management | HPE iLO 6 |
| Rail Kit | HPE ProLiant DL3XX Gen11 Easy Install Rail 3 Kit Notes: Server does not support shelf mounted rail kits ("L" brackets). |
| Security | TPM (Trusted Platform Module) |
| Form Factor | 1U Rack |
| Warranty | Server warranty includes 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
.
